CA 505-01-10

Description of the Two-Phase-Decanter:

This clarifying decanter is a continuously operating full mantle worm screen centrifuge for the separation of solids from suspensions, equipped with a peeling disc for the discharge of the clarified liquid under pressure.

Materials:

All parts in contact with the spun material are made of CrNiMo steel. All sealing elements in contact with the spun material are made of NBR (Perbunan).

Housing:

The supporting housing parts are made of quality grey cast iron. The solids collection chamber is lined with 1.4404 and equipped with mating flange and seal.

Bowl and Worm:

The decanter is equipped with an 8° flat cone bowl. For wear protection, the solids discharge is equipped with replaceable stainless steel bushes.

Drive:

The bowl is driven by a 90 KW three-phase motor, protection class: IP 55 via a fluid coupling.

Spun material connection:

The centrifugal feed is equipped with an elastic connecting piece with flanges according to DIN 2633.

Pond depth adjustment:

Quantity-independent pneumatic pond depth adjustment using the patented Varipond P system.
